PreSonus StudioLive 24R 24 Channel Rackmount Digital Mixer

Presonus StudioLive 24R 26-input, 24-channel Series III stage box and rack mixer.

Powerful and compact, the PreSonus StudioLive 24R serves as a 24-channel AVB stage box for StudioLive Series III consoles and as a standalone, rack-mount, 24-channel, Series III digital mixer. It can operate as a simple stage box or as a combined stage box/24-channel monitor mixer, delivering a plug-in-style signal-processing workflow with studio-quality, vintage-style EQ and compression options on every channel.

• AVB stage box for StudioLive Series III consoles with simple stage box mode and stage box + monitor mixer mode
• Fully recallable, 24-channel, Series III digital rack mixer
• 26 total inputs, including 24 locking combo mic/line channel inputs with recallable XMAX Class A mic preamps
• 16 FlexMixes (Aux mixes, Subgroups, or Matrix mixes) and 4 dedicated subgroups
• 40x40 USB 2.0 recording interface and 55x55 AVB recording interface
• Complete solution: Includes UC Surface touch-control software for Mac, Windows, iPad, and Android; Capture™ live-recording software and Studio One® Artist DAW for Mac and Windows; compatible with free QMix-UC® personal
• monitoring control for iPhone®/iPod® touch, and Android™

Take your studio or live shows into the future with this digital rack mixer—order today.

• Analog/digital: Digital
• Number of channels: 24
• Busses/groups: 4
• Aux sends: Yes
• Powered: Yes

• Total inputs: 26
• Mic preamps: 24
• XLR/TRS combo jacks: 24
• XLR only jacks: 0
• 1/4" only jacks: 0
• S/PDIF in: Not Specified
• ADAT/optical in: Not Specified
• RCA in: 2
• AES/EBU: Not Specified

• Total outputs: 14
• XLR out: 2
• 1/4" out: 12
• S/PDIF out: Not Specified
• ADAT/optical out: Not Specified
• RCA out: Not Specified
• AES / EBU: Not Specified

• Connections: USB
• MIDI I/O: Not Specified
• Headphone output(s): Yes
• Wi-Fi Not Specified
• Word-clock I/O: Not Specified
• I/O expansion: Not Specified

• Compression: Yes
• Reverb: Yes
• Delay: Yes
• Chorus/flange: Not Specified

• Type: Parametric
• EQ bands: 6
• Master graphic: Not Specified

• Width: Not Specified
• Height: Not Specified
• Depth: Not Specified
• Weight: Not Specified
• Automation: Not Specified
• Fader type: Digital
• Motorized faders: Not Specified
• Bundled software: Yes
• Rackmountable: Yes
